Specs
| 8.6 HDV | 9.6 HDV | |
|---|---|---|
| Moldboard Options | Stainless or Powder-Coated Steel | Stainless or Powder-Coated Steel |
| Moldboard Options | Stainless or Powder-Coated Steel | Stainless or Powder-Coated Steel |
| Blade Type | V-Plow | V-Plow |
| Blade Type | V-Plow | V-Plow |
| Vehicle Compatibility | Truck Class 2 - 6 (under 26,000 lb GVWR) & Tractors | Truck Class 2 - 6 (under 26,000 lb GVWR) & Tractors |
| Vehicle Compatibility | Truck Class 2 - 6 (under 26,000 lb GVWR) & Tractors | Truck Class 2 - 6 (under 26,000 lb GVWR) & Tractors |
| Approx. Weight* | 950 lbs | 1,020 lbs |
| Approx. Weight* | 430 kg | 462 kg |
| Plowing Width (Straight) | Straight: 102" - 112.5" (w/ Wings) V: 92" - 115" (w/ Wings) Scoop: 86" - 98" (w/ Wings) | Straight: 114" - 124.5" (w/ Wings) V: 103" - 126" (w/ Wings) Scoop: 98" - 110" (w/ Wings) |
| Plowing Width (Straight) | Straight: 259 cm - 285.8 cm (w/ Wings) V: 233.7 cm - 292.1 cm (w/ Wings) Scoop: 218.4 cm - 249 cm (w/ Wings) | Straight: 289.5 cm - 316.2 cm (w/ Wings) V: 261.6 cm - 320 cm (w/ Wings) Scoop: 249 cm - 279.4 cm (w/ Wings) |
| Plowing Width (Full Angle) | 90" -115" w/ Wings | 103.2" - 118" w/ Wings |
| Plowing Width (Full Angle) | 228.6 cm - 292.1 cm w/ Wings | 262.1 cm - 299.7 cm w/ Wings |
| Blade Width | 8'6" | 9'6" |
| Blade Width | 259.1 cm | 289.6 cm |
| Blade Height | At Hinge: 31" At End: 38" | At Hinge: 31" At End: 39" |
| Blade Height | At Hinge; 78.7 cm At End: 96.5 cm | At Hinge: 78.7 cm At End: 99.1 cm |
| Angle Cylinders | 1.75" x 11" | 1.75" x 11" |
| Angle Cylinders | 4.4 cm x 27.9 cm | 4.4 cm x 27.9 cm |
| Cutting Edge | ⅜" (Standard) | ½" (Standard) |
| Cutting Edge | 0.953 cm (Standard) | 1.3 cm (Standard) |
| Blade Thickness | 16 ga | 16 ga |
| Blade Thickness | 16 ga | 16 ga |
| Reinforcement Ribs | 6 vertical/1 angle | 8 vertical/1 angle |
| Reinforcement Ribs | 6 vertical/1 angle | 8 vertical/1 angle |
| Trip Springs | 4 steel | 6 steel |
| Trip Springs | 4 steel | 6 steel |
