Specs
| Models | 8' | 10' | 8' (36"H) | 10' (36"H) | 12' | 14' | 16' |
|---|---|---|---|---|---|---|---|
| Moldboard Options | Powder-Coated Steel | Powder-Coated Steel | Powder-Coated Steel | Powder-Coated Steel | Powder-Coated Steel | Powder-Coated Steel | Powder-Coated Steel |
| Moldboard Options | Powder-Coated Steel | Powder-Coated Steel | Powder-Coated Steel | Powder-Coated Steel | Powder-Coated Steel | Powder-Coated Steel | Powder-Coated Steel |
| Blade Type | Pusher | Pusher | Pusher | Pusher | Pusher | Pusher | Pusher |
| Blade Type | Pusher | Pusher | Pusher | Pusher | Pusher | Pusher | Pusher |
| Vehicle Compatibility | Skid-Steer | Skid-Steer | Tractor / Wheel Loader | Tractor / Wheel Loader | Tractor / Wheel Loader | Wheel Loader | Wheel Loader |
| Vehicle Compatibility | Skid-Steer | Skid-Steer | Tractor / Wheel Loader | Tractor / Wheel Loader | Tractor / Wheel Loader | Wheel Loader | Wheel Loader |
| Approx. Weight* (Without Mount) | 2,533 lb | 2,770 lb | 2,628 lb | 2,822 lb | 3,197 lb | 3,666 lb | 3,855 lb |
| Approx. Weight* (Without Mount) | 1,148.9 kg | 1,256.5 kg | 1,192.0 kg | 1,280.1 kg | 1,450.1 kg | 1,662.9 kg | 1,748.6 kg |
| Application Weight (Max Operating Weight) | 8,000 lb | 9,000 lb | 10,000 lb | 12,000 lb | 25,000 lb | 30,000 lb | 35,000 lb |
| Application Weight (Max Operating Weight) | 3,628.7 kg | 4,082.3 kg | 4,535.9 kg | 5,443.1 kg | 11,339.8 kg | 13,607.8 kg | 15,875.7 kg |
| Horsepower Compatibility | 45+ hp (Skid-Steer) | 60+ hp (Skid-Steer) | 40+ hp (Tractor) & 60+ hp (Wheel Loader & Backhoe) | 50+ hp (Tractor) & 60+ hp (Wheel Loader & Backhoe) | 100+ hp (Wheel Loader & Backhoe) | 140+ hp (Wheel Loader & Backhoe) | 140+ hp (Wheel Loader & Backhoe) |
| Horsepower Compatibility | 45+ hp (Skid-Steer) | 60+ hp (Skid-Steer) | 40+ hp (Tractor) & 60+ hp (Wheel Loader & Backhoe) | 50+ hp (Tractor) & 60+ hp (Wheel Loader & Backhoe) | 100+ hp (Wheel Loader & Backhoe) | 140+ hp (Wheel Loader & Backhoe) | 140+ hp (Wheel Loader & Backhoe) |
| Blade Width | 8' | 10' | 8' | 10' | 12' | 14' | 16' |
| Blade Width | 2.44 m | 3.05 m | 2.44 m | 3.05 m | 3.66 m | 4.27 m | 4.88 m |
| Blade Height | 30" | 30" | 36" | 36" | 42" | 42" | 42" |
| Blade Height | 76.2 cm | 76.2 cm | 91.44 cm | 91.44 cm | 106.68 cm | 106.68 cm | 106.68 cm |
| Side Plate Width | 36" | 36" | 36" | 36" | 36" | 36" | 36" |
| Side Plate Width | 91.44 cm | 91.44 cm | 91.44 cm | 91.44 cm | 91.44 cm | 91.44 cm | 91.44 cm |
| Side Plate Height | 30" | 30" | 36" | 36" | 42" | 42" | 42" |
| Side Plate Height | 76.2 cm | 76.2 cm | 91.44 cm | 91.44 cm | 106.68 cm | 106.68 cm | 106.68 cm |
| Moldboard Radius | 27" | 27" | 27" | 27" | 46" | 46" | 46" |
| Moldboard Radius | 68.58 cm | 68.58 cm | 68.58 cm | 68.58 cm | 116.84 cm | 116.84 cm | 116.84 cm |
| Approx. Snow Capacity | 75 cu ft | 94 cu ft | 108 cu ft | 135 cu ft | 219 cu ft | 250 cu ft | 281 cu ft |
| Approx. Snow Capacity | 2.12 cu m | 2.66 cu m | 3.06 cu m | 3.82 cu m | 6.20 cu m | 7.08 cu m | 7.96 cu m |
| Cutting Edge Technology | TRACE — Terrain Response Advanced Cutting Edge | TRACE — Terrain Response Advanced Cutting Edge | TRACE — Terrain Response Advanced Cutting Edge | TRACE — Terrain Response Advanced Cutting Edge | TRACE — Terrain Response Advanced Cutting Edge | TRACE — Terrain Response Advanced Cutting Edge | TRACE — Terrain Response Advanced Cutting Edge |
| Cutting Edge Technology | TRACE — Terrain Response Advanced Cutting Edge | TRACE — Terrain Response Advanced Cutting Edge | TRACE — Terrain Response Advanced Cutting Edge | TRACE — Terrain Response Advanced Cutting Edge | TRACE — Terrain Response Advanced Cutting Edge | TRACE — Terrain Response Advanced Cutting Edge | TRACE — Terrain Response Advanced Cutting Edge |
| Cutting Edge Material | High-Carbon Steel With Carbide Inserts | High-Carbon Steel With Carbide Inserts | High-Carbon Steel With Carbide Inserts | High-Carbon Steel With Carbide Inserts | High-Carbon Steel With Carbide Inserts | High-Carbon Steel With Carbide Inserts | High-Carbon Steel With Carbide Inserts |
| Cutting Edge Material | High-Carbon Steel With Carbide Inserts | High-Carbon Steel With Carbide Inserts | High-Carbon Steel With Carbide Inserts | High-Carbon Steel With Carbide Inserts | High-Carbon Steel With Carbide Inserts | High-Carbon Steel With Carbide Inserts | High-Carbon Steel With Carbide Inserts |
| Mount Type | Skid-Steer Attach Plate | Skid-Steer Attach Plate | Skid-Steer Attach Plate / Coupler | Skid-Steer Attach Plate / Coupler | Coupler | Coupler | Coupler |
| Mount Type | Skid-Steer Attach Plate | Skid-Steer Attach Plate | Skid-Steer Attach Plate / Coupler | Skid-Steer Attach Plate / Coupler | Coupler | Coupler | Coupler |
